General Specifications
| Product Number | BAT-XGE-ST001 |
| EAN Code | 4042673920533 |
| Suitable for | 250 µm and 900 µm bare fibers |
| Mounting Type | Wall-Mountable |
| Application | Indoor/Outdoor |
Standards
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
Environmental Conditions
| Temperature Range, Installation | -33 °C to 70 °C (-27.4 °F to 158 °F ) |
| Temperature Range, Operation | -33 °C to 70 °C (-27.4 °F to 158 °F ) |
| Temperature Range, Storage | -25 °C to 70 °C (-13 °F to 158 °F ) |
Design
| Splice Tray Type | Own |
| Housing Material | PC ABS |
| Additional cable number reachable with accessories | 64 |
| Maximum cable number in basic unit with accessories | 20 |
| Number of Blank Modules | 44 |
| Cable entry type | Grommeted Slot |
| Number of Splice Trays | 3 |
| Pigtail Type | Individual with natural primary coating and yellow secondary coating |
| Number of Adapters | 20 |
Design - Adapter
| Housing Color | Green |
| Housing Material | Composite |
| Keyed adapter | Yes |
| Shuttered adapter | No |
Optical Specification - Hardware
| Pigtail insertion loss | 0.35 dB |
Specifications - Connector A
| Connector Type | LC duplex |
Dimensions
| Height | 390 mm |
| Width | 450 mm |
| Depth | 88 mm |
| Weight | 2.5 kg |
Ordering Information
| Package Contents | 4 screws and 4 dowels |
| Shipping Weight | 2.5 kg |
| Units per Delivery | 1/1 |
| Shipping Height | 100 mm |
| Shipping Width | 500 mm |
| Shipping Depth | 500 mm |
