KIT12-001701K4Z43AA002M
Professional Fibre Optic Pigtail Kit 12 pcs Pigtail FC connectors, 900 µm LSZH TB3, 62.5 µm multimode (OM1), 2 m
General Specifications
| Product Number | KIT12-001701K4Z43AA002M |
| Flame rating | LSZH/FRNC |
| Fibre category | 62.5 µm MM (OM1) |
| Cable assembly type | Single fibre |
| Cable Type | Tight-buffered |
Standards
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Intermateability | TIA/EIA-604-4 |
Environmental Conditions
| Temperature range, installation | -5 °C to 50 °C |
| Temperature range, operation | -10 °C to 60 °C |
| Temperature range, storage | -10 °C to 60 °C |
Design
| Fibre count | 1 |
| Outer jacket material | LSZH/FRNC |
| Polarity | Classic |
| Fibre colouring | Blue, orange, green, brown, grey, white, red, black, yellow, violet, pink, turquoise |
Mechanical Characteristics
| Strip length | 100 mm |
| Min. bend radius installation | 30 mm |
Optical Characteristics
| Fibre code | K |
| Performance option code | 08 |
| Fibre category | OM1 |
| Fibre Type | Multimode |
| Fibre name | 62.5 µm MM (OM1) |
| Maximum Attenuation | 3.1 dB/km / 0.8 dB/km |
| Wavelengths | 850 nm / 1300 nm |
| Fibre compliance | ISO/IEC 11801 |
| Fibre core diameter | 62.5 µm |
| Cladding diameter | 125 µm |
| Coating diameter | 242 µm |
| Serial 1 gigabit ethernet | 300 m / 550 m |
| Serial 10 gigabit ethernet | 33 m / - |
Specifications - Connector B
| Polish | PC |
| Insertion loss, max. | 0.5 dB |
| Durability | ≤ 0.2 dB change, 1000 rematings, FOTP-21 |
| Boot colour | Black |
| Connector type | FC |
| Ferrule material | Ceramic |
| Housing colour | Nickel |
| Housing material | Metal |
| Boot type | Individual |
Dimensions
| Length | 2 m |
| Outer diameter | 0.9 mm |
Ordering Information
| Packaging method | Cardboard box |
| Units per delivery | 1/1 |
| Shipping Height | 180 mm |
| Shipping Width | 250 mm |
| Shipping Depth | 380 mm |
