D14801EB49R007F-P
Evolv® Maintenance Extender Inline Drop with Pushlok® Technology 1F Pushlok to 1F Inline, Dielectric, 7 ft, individual packaging
General Specifications
| Product Number | D14801EB49R007F-P |
| Cable Type | ROC™ dielectric drop |
| Assembly Insertion Loss | ≤ 0.4 dB |
| Connector Assembly Type | Pushlok Inline |
| Packaging | Individual Pack |
Standards
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
Design
| Fiber Count | 1 |
Optical Characteristics
| Fiber Code | E |
| Performance Option Code | 01 |
| Fiber Category | OS2 |
| Fiber Type | Single-mode (OS2) / 250 µm |
| Fiber Name | Single-mode (OS2) |
| Maximum Attenuation | 0.4 dB/km / 0.4 dB/km / 0.3 dB/km |
| Wavelengths | 1310 nm / 1383 nm / 1550 nm |
| Fiber Compliance | ITU-T G.652.D |
Specifications - Connector A
| Insertion Loss, Max. | 0.4 dB |
| Connector Type | Pushlok |
| Reflectance | ≤ -65 dB |
Specifications - Connector B
| Insertion Loss, Max. | 0.4 dB |
| Connector Type | Inline |
| Reflectance | ≤ -65 dB |
Dimensions
| Length | 7 ft |
Ordering Information
| Packaging Method | Box |
| Units per Delivery | 1/1 |
Reduced terminal size
Inline drop enables users to replace existing MultiPort terminals with Evolv terminals that are up to 2x smaller
Hardened connector technology
Reduced-diameter Pushlok® connector
Drop replacement cost avoidance
When replacing MultiPort terminals, avoid additional costs with replacing OptiTap drops by leveraging this inline technology to convert from OptiTap to Pushlok
